Short Compressor Replacement Kit
SKU: UKA591551
Brand: KABAIR
Price: List price: C$460.69 CAD
Description
Short Compressor Replacement KitSpecifications
| Superheat | 3.2 |
| Grooves | 4 |
| Rotation | A Direction |
| Refrigerant | HFC-134A |
| Voltage | DC 12V |
| Hub Type | DENSO |
| Outlet Fitting | Sealing Washer |
| Compressor Type | 10S20F |
| Max Operating Pressure | 0.45±0.0345 |
| Inlet Type | Sealing Washer |
| Connector Gender | Male |
| Height (mm) | 225 |
| Inlet (mm) | M16 |
| Inlet (mm) | 26 |
| Outlet (mm) | M20 |
| Diameter (mm) | 9.6 |
| Pulley Diameter (mm) | 110 |
| Terminal Qty | 2 |
| Inner Diameter (mm) | 7.3 |
| Wire Qty | 1 |
| Capillary Length (mm) | 120 |
| KIT: COMPRESSORS | CO 29002C |
| KIT: ACCUMULATORS/DRIERS | RD 10070C |
| KIT: EXP VALVES/ORIF TUBE | EX 5378C |
| KIT: EXP VALVES/ORIF TUBE | EX 5734C |
| Length (mm) | 91 |
| Discharge Port (mm) | 11 |
| Width (mm) | 87.5 |
| Compressor Mount | EAR MOUNT |
| Connector Terminal Qty | 2 |
| Material Type | plastic/ cloth |
| Color | Black |
| Clutch Included | Yes |
| Compatible Refrigerant Oil Type | PAG-180 |
| Oil Filled | PAG 46 |
| Pulley Belt Type | Serpentine |
| Refrigerant Type | HFC-134A |
| Refrigerant Type | R12;R134A |
| Switch Included | No |
| Terminal Type | Spade |
| Clutch Maximum Diameter | 110 |
| Mounting Type | Tangent |
| Screen Micron Rating | 120 |
| Coil Voltage | 12 |
| Connector Quantity | 1 |
| Mounting Flange Thickness | 10 |
| Pulley Lip Diameter | 138 |
| Wire Gauge Measurement | 130 |
| Coil Clock Position | 12 |
| Connector Shape | Round |
| Discharge Port Inside Diameter | 8 |
| Distance From Clutch To Mounting Flange | 72.5 |
| Mounting Hole Quantity | 4 |
| Suction Port Inside Diameter | 26.3 |
| Tube Outside Diameter | 9.8 |
| Casing Outside Diameter | 161.5 |
| Distance Between Mounting Holes | 126 |
| Pulley Groove Quantity | 4 |
| Pulley Outside Diameter | 110 |
| Pulley Ridge Diameter | 3.16 |
OEM Number(s)
Contact a KABAIR representative for more information.
